Description
Round Toggle Switch On Off SPST LED Ring RGB 20A, This switch is designed for specific applications where a toggle switch is required for panel mount use.
- Ratings: 20A @12V
- Connection: 6Pin Terminals
- LED Color: Red, Green, Blue (Selectable via switch pin)
- Panel Cutout: 16mm
- Function: ON-OFF SPST
- Pins: 2.8mm Spade, leads supplied
- Waterproof IP67 rating
- Contact Resistance: ≤25mΩ
- Insulated Resistance: ≥100MΩ
- Dielectric Strength: 1 Minute 1500V AC
- Operating Temperature: -25℃~+55℃
- Electrical Life: ≥10,000 Cycles
