Description
The Roadvision Stealth S70 is a single-row LED light bar built around projector beam optics, which push more usable light out of a slim housing than a conventional reflector bar. Each bar mixes driving and spot projectors into a combo beam, giving strong long-range punch down the road or track with enough spread to light the verges.
Osram Hi-Lux 3W LEDs produce a crisp 5,700K white close to daylight, from 3,300 lumens on the 7″ bar up to 27,500 lumens on the 52″. The die-cast aluminium housing, smoked polycarbonate lens and Roadvision thermal management keep the LEDs cool for a 50,000-hour life, and the bar is sealed to IP68 and IP69K for mud, water and high-pressure wash-downs.
The S70 Pro versions (13″, 21″ and 30″) add a dynamic start-up dual-colour DRL that can run in amber or white. All bars run on 10–30V for 12V and 24V vehicles, include blackout mounting hardware with adjustable anti-vibration end mounts and low-profile slide mounts, and are backed by Roadvision’s 7-year warranty.
Key Benefits
- Projector combo beam – driving and spot optics in one bar
- Up to 27,500 lumens and over 2.2 km of beam reach (52″)
- Slim single-row profile for bull bars, roof racks and grilles
- IP68 and IP69K sealed for mud, water crossings and wash-downs
- Multi-volt 10–30V for 12V and 24V vehicles
- S70 Pro option with dynamic amber/white DRL
- 7-year Roadvision warranty
Specifications
- Brand – Roadvision
- Series – Stealth S70 / S70 Pro (DRL)
- Sizes – 7″, 13″, 21″, 30″, 40″ and 52″ (Pro: 13″, 21″, 30″)
- Beam pattern – Projector combo (driving + spot)
- Maximum output – 3,300 lm (7″) to 27,500 lm (52″)
- Power – 48W (7″) to 425W (52″)
- LEDs – Osram Hi-Lux 3W, 5,700K
- Input voltage – 10–30V DC multi-volt
- Ingress protection – IP68 and IP69K
- Housing / lens – Die-cast aluminium / polycarbonate, smoked finish
- Mounting – 9-position adjustable anti-vibration end mounts and low-profile slide mounts, blackout hardware
- Protection – Over/under voltage, reverse polarity, EMI/EMC radio interference approved
- Wiring – 2-pin Deutsch (7″, 13″), 2-pin ATP (21″, 30″), flying leads (40″, 52″); Pro: 4-pin Deutsch / ATP
- LED life – 50,000 hours
- Warranty – 7 years
- Part numbers – select a size and version above to see the Roadvision part number
Applications
- 4WD, touring and off-road vehicles
- Utes and work vehicles
- Trucks and road trains
- Mining and site vehicles
- Farm and station vehicles
