Description
The ECCO EW2520 is a 24-LED square flood work lamp using twenty-four 1.5 W LEDs. It is built for trucks, utes, service bodies, tow trucks, plant and machinery that need reliable light to work by.
The EW2520 gives very bright white light from a compact design with a low current draw. It is CISPR 25 EMC compliant, has a built-in vent to prevent fogging and is rated for over 80,000 hours of maintenance-free life.
It runs on 12–24V DC and draws about 1.8 A. Mounting: bracket mount.
Key Benefits
- Twenty-four 1.5 W LEDs, flood beam
- Low 1.8 A current draw
- Built-in vent to prevent lens fogging
- Over 80,000 hours LED life
- IP67 and IP69K sealed, 5-year warranty
Specifications
- Part number – EW2520
- Series – ECCO EW2520 Series
- Type – Work Lamp
- Light colour – White
- Light output – 3125 (raw) lumens
- Beam – Flood
- Voltage – 12–24V DC
- Current draw – 1.8 A
- Dimensions – 107 × 129 × 48 mm
- Mounting – Bracket mount
- Approvals – CE, CISPR 25, IP67, IP69K, RoHS
- Warranty – 5 years
Applications
- Tow trucks and service vehicles
- Utes, work trucks and headache racks
- Earthmoving, agricultural and mining equipment
- Trailers, tippers and mobile plant
