SKU: TYRI 1323TYRI
TYRI
TYRI 1323Massive output · up to 16,500 effective lumens · 4,000 K · 24V DC or 240V AC

Extremely powerful LED flood light from TYRI delivering up to 16,500 effective lumens, with a curved design and 60° trunnion mount. 24V DC or 100–277V AC for lighting towers and fixed plant. See the full TYRI range.

🚚Dispatch times may vary on this item. Please contact us for current availability.
💬Have a question about this product? Our team can help with specs, compatibility, or a custom quote — ask a question.

SKU: TYRI-1323 Category:
TYRI part numbers (2 versions)
VersionTYRI part no.
24V · 16,500 lmJLU-001-1
100–277V AC · 16,500 lmJLU-002-1

TYRI 1323 LED Flood Light 13,500–16,500 Lumen 24V / 240V AC part numbers. Select the version above to see its full specification.

Description

The TYRI 1323 is an extremely powerful LED work light delivering a massive 16,500 effective lumens at 4,000 K. Its curved design and 60° trunnion mount make it suitable for many installation positions, and a twin bracket is available for dual mounting.

It is used on fire-fighting vehicles, boat and mobile cranes, material handlers, mining machines and generator light masts.

Choose 24V DC or 100–277V AC above to see the TYRI part number. The AC version is ideal for lighting towers, conveyors and stationary plant.

Key Benefits

  • Up to 16,500 effective lumens
  • 4,000 K neutral white
  • 60° trunnion mount, twin bracket option
  • 24V DC or 100–277V AC versions
  • ECE R10 (DC version)

Specifications

  • Brand – TYRI (Sweden)
  • Product – 1323
  • Effective lumen – 16,500 lm / 13,500 lm
  • Machine voltage – 24V / 100–277V AC
  • Lens patterns – Medium Symmetric
  • Colour temperature – 4,000 K
  • Power – 150 W (24V DC) / 170 W (AC)
  • Current draw – 6.2 A at 24V
  • Light source – LED
  • Mounting – Hanging, Standing
  • Part numbers – 3 versions – select above to see the part number

Applications

  • Construction and earthmoving equipment
  • Cranes and lifting equipment
  • Fire, rescue and emergency vehicles
  • Forestry machines
  • Marine and boat applications
  • Mining and quarry equipment
