LED Work Light 12V 24V Spot Light Waterproof with Lens Guard TYRI CLD-211-1G is a work light designed for commercial vehicles, mobile plant, industrial equipment and demanding transport applications. Select the product to suit the required lighting function, mounting position and operating environment.
Key Selection Points
- Lighting function: Work light
- Confirm the required supply voltage and electrical connection
- Check mounting position, available clearance and orientation
- Match the beam, lens or signal function to the application
- Verify environmental protection requirements for the installation
Product Details
TYRI Work Light 1800 Lumen Spot 1010 Curve with Grille (CLD-211-1G) has a compact housing, is a great option when space is limited. Vibration dampers are standard, providing an advantage when the ground is uneven. The 1010 Curve is suitable for use on heavy machinery where work lighting is required.
Suggested application
The 1010 Curve is highly adaptable and can be used across numerous applications worldwide, including construction, mining, forestry, material handling and port material handling.
Specifications:
- Light Pattern: Spot
- Protective Grille Included
- Lumens: 1800 (1450eLm)
- Voltage: 12-48V
- Amperage: 2.5A @12V, 1.3A @24V
- Power: 30 Watts
- Connection: 2 Pin Deutsch Socket, Lead included.
- Color Temperature: 5,700 K
- Made in: USA
Test Standards:
- Salt Spray ASTM B117 500 h
- Vibration 5-2000 Hz 3 Axis, 10 Grms
- Shock Tested 50 G 11 ms
- IP69K
- EN55025 / CISPR 25 Class 4 & 5,
ISO7637-2, ISO10605, ISO16750-2,
ISO11452-2, ISO11452-4 - R10, R23
Applications
- Commercial and fleet vehicles
- Mining, construction and agricultural machinery
- 4WD, off-road and utility vehicles
- Industrial and materials-handling equipment
Confirm voltage, light function, beam or lens pattern, dimensions, mounting and connector requirements before ordering.
