Description
The ECCO 610N is a 600 Series back-up alarm, built to meet the harsh operating demands of fleet equipment. Its reverse-mounted speaker improves sound projection and keeps dust and moisture away from the speaker, while the reinforced nylon housing eliminates corrosion damage.
It produces a fixed 97 dB(A) tonal warning. It runs on 12–36V DC and draws 0.4 A, with SAE Type C, CE, ECE R10, UL, AMECA, IP64 approvals.
The electronics are sealed in epoxy, the alarm is steam cleanable and pressure washable, and it works on positive or negative ground systems from −40 °C to +85 °C. Wiring is via 16 AWG blunt-cut leads and it mounts with 5/16-18 UNC Grade 5 bolts. Warranty: ECCOLIFE (life of the vehicle).
Key Benefits
- Reverse-mounted speaker protects against dust and moisture
- 97 dB(A) tonal output
- Reinforced nylon housing – no corrosion
- Steam cleanable and pressure washable
- Works on positive or negative ground systems
- 12–36V DC, 0.4 A draw
- Warranty: ECCOLIFE (life of the vehicle)
Specifications
- Part number – 610N
- Brand – ECCO
- Series – 600 Series
- Type – Tonal Back-Up Alarm
- Sound output – 97 dB(A)
- Operating voltage – 12–36V DC
- Current draw – 0.4 A
- Dimensions – H 79 × W 127 × D 69 mm
- Mounting – 2-bolt
- Approvals – SAE Type C, CE, ECE R10, UL, AMECA, IP64
- Operating temperature – −40 °C to +85 °C
- Warranty – ECCOLIFE (life of the vehicle)
Applications
- Trucks, tippers and prime movers
- Earthmoving and construction plant
- Refuse and municipal fleets
- Mining and quarry vehicles
